C6 EM8X55
Weldon DIN 6359/DIN 6359 form B end mill holders with C-ADAPTER (ISO 26623-1) taper shanks
| Shank Type | Weldon | Measurement Type | Metric |
| Connection Diameter Workpiece Side (DCONWS) | 8 mm | Connection Retention Knob Thread Size (CRKS) | M20 |
| Body Diameter (BD) | 28 mm | Shank Size (SS) | 63 mm |
| Body Length Maximum (LBX) | 55 mm | Body Material | Steel |
| Nose Length | 33 mm | Unit | M |
| Application | | ISO 26623 1 C ADAPTER | |
Product Features
| Family Description | Weldon DIN 6359/DIN 6359 form B end mill holders with C-ADAPTER (ISO 26623-1) taper shanks | FamilyName | C-EM |
| COO | ISRAEL | BrandName | Taegutec |
Shipping Info
Weight per item
1.0000
Name
End Mill Holders
FamilyName
C-EM
BrandName
Taegutec
