4N TE90-320-20-06-L110
90° End mills with unique 4 high positive helical cutting edges of double-sided 4NK(H)T 06 inserts & high ramping
| Cutting Diameter (DC/DCX) | 20 mm | Connection Diameter Machine Side (DCONMS) | 20 mm |
| Cutting Diameter (DC) | 20 mm | Master Insert Identification (MIID) | 4NKT 060308R-M |
| Cutting Item Count (CICT) | 3 | Head Length (LH) | 25 mm |
| Depth of Cut Maximum (APMX) | 6 mm | Measurement Type | Metric |
| Overall Length (OAL) | 110 mm | Body Material | Steel |
| Shank Type | Round | Unit | M |
| Application | | Facing | Helical Interpolation | High Feed Milling | Profiling | Rampdown | Shouldering | Slotting | Step down machining | |
Product Features
| Family Description | 90° End mills with unique 4 high positive helical cutting edges of double-sided 4NK(H)T 06 inserts & high ramping | FamilyName | 4N TE90-06 |
| Remarks | Cutter body for '4NKT 060320R HF' and '4NHT 060320R F' inserts should be modified with body corner radius 2.0 mm | BrandName | Taegutec |
| COO | S.KOREA |
Shipping Info
Weight per item
0.3000
Name
Indexable End Mills
FamilyName
4N TE90-06
BrandName
Taegutec
