TMS-25H SVUBL 11-TB
Screw type high pressure coolant sleeve holders with 93° approach angle & 35° VB.T positive inserts for Swiss type automatic lathes
| Shank Height (H) | 23 mm | Body Material | Steel |
| Functional Width (WF) | 10 mm | Measurement Type | Metric |
| Cutting Direction (HAND) | Left Hand | Unit | M |
| Application | | Ext 93° App Sleeve 35° Diamond | Tools for Swiss Machines | |
Product Features
| Family Description | Screw type high pressure coolant sleeve holders with 93° approach angle & 35° VB.T positive inserts for Swiss type automatic lathes | FamilyName | TMS-SVUBR/L-TB |
| COO | S.KOREA | BrandName | Taegutec |
Shipping Info
Weight per item
0.3250
Name
General Indexable Turning Tools
FamilyName
TMS-SVUBR/L-TB
BrandName
Taegutec
